Raw material
1. The raw material of outlet of fire: made of fire-proof material, make the life 5 times longer than other supplier.
2. Dual protection system, avoid fire back to make raw material burning in conveyor.
3. One pipe connect with air box, blow away raw material, make them distribute evenly in combustor.
4. Easy feeding of biomass burner, and customize the storage silo of raw material.
5. Fuel material: biomass pellets, fruit shells, wood chips etc.
6. Wide range of capacity: from 200,000kcal to 3,600,000kcal.
Raw material
Parameter
Model | Thermal power 10000(kcal) | power(kw) | Biomass consumption (kg/h) | dimensions(mm) | weight(t) |
YGF-45 | 45 | 1.12 | 115 | 1830*1100*2130 | 1.0 |
YGF-60 | 60 | 1.9 | 150 | 2340*980*2180 | 1.6 |
YGF-90 | 90 | 3.1 | 225 | 2790*1190*2400 | 2.2 |
YGF-120 | 120 | 3.7 | 300 | 2900*1300*2420 | 3.0 |
YGF-180 | 180 | 5.25 | 450 | 3180*1490*2400 | 3.8 |
YGF-240 | 240 | 8.45 | 600 | 3250*1660*2520 | 4.8 |
Exhibition pictures
Certification
Our company has gained ISO9001-2000 Certification, CE Certification, SGS Certification patent etc. Products cover the environmental carbon, biomass, urban and rural environment, culture and other fields. There are five main series: the biomass compression molding equipment, garbage disposal equipment for urban and rural, organic fertilizer equipment, Feeder Equipment and Environmental protection equipment.
Service/policy/warranty or after-sales service
Free Raw Material Test
We can do free raw material test for you. You just need to send your raw material to us, and we will find the best way to make pellets with it.
24-Hour online customer service guide by phone or any contact at any time.
48-Hour engineer's door-to-door service Save customers waiting time in maximum to raise their satisfaction
